Building the Protego Images

 SECRET//NOFORN

Building the Protego Images
Introduction
This document describes the builds required for a complete Protego system.
Processor images built for the Protego system:
There are seven build images created for a complete Protego system.
The following build images are unique for each Collar, Tube, and Missile set and the
keys must match:
1) P1.X.production.hex
2) P2.X.production.hex
3) P3.X.production.hex
The following are used on the Deployment Box for configuration control of any
Protego system:
4) P4.X.production.hex
5) P5.X.production.hex
The following build images are used when reprogramming the MP processor:
6) P1_S.X.production.hex
7) P2_ Maintenance.production.hex
Locations of images:
1) P1 - Master Processor (MP), Master Processor on PWA
2) P1_S - Master Processor (MP), Slave Processor on PWA
3) P2 - Tube Smart Switch (TSS) Processor
4) P3 - Missile Smart Switch (MSS) Processor
5) P4 - Deployment Box Slave Processor on PWA
6) P5 - Deployment Box Master Processor on PWA
7) P2_Maintenace - Tube Smart Switch (TSS) Processor
Processor images descriptions:
SECRET//NOFORN
SECRET//NOFORN
An example of build images for a complete system with key number 3002 would be:
• 3002_P1.X.production.hex (MP Master uC image)
• 3002_P2.X.production.hex (TSS uC image)
• 3002_P3.X.production.hex (MSS uC image)
Since the Deployment Box does not contain any keys, the images for the
Deployment Box would be:
• P4.X.production.hex (Deployment Box Master uC image)
• P5.X.production.hex (Deployment Slave uC image)
For reprogramming the MP master processor, the P1_S.X (P1 Slave) and
maintenance image P2_Maintenace are created using an engineering maintenance
key located within the images. They would be:
• P1_S.X. production.hex (MP Slave uC image)
• P2_ Maintenace.production.hex (TSS reprogramming P2 uC image)
These two images are used on any Protego system, regardless of key, to
reprogram the MP master processor
Step 1: Building the Initial Protego Images (No Keys)
Open the C:\RMS_Programs directory in the command line prompt and execute the
build_protego.bat script. This will build files for each image which consist of .hex,
.elf, and .map files. These files will be located in a new time stamped _build
directory within the RMS_Programs directory.
Only P1, P2, and P3 images need keys added to their images.
File descriptions:
.hex file - Build image in Intel hex format that conveys binary information in the
ASCII text form. This file is used when loading the image on the processor.
.elf file - Executable and Linkable Format is a common standard file format for
description of executables, object code, and shared libraries.
.map file - The map file shows information relating to where objects were positioned
in memory. It
is useful for confirming if user-defined linker options were correctly processed, and
for
SECRET//NOFORN
SECRET//NOFORN
determining the exact placement of objects and functions.
Step 2: Generating Keys:
Note:
To aid in keeping the key numbers grouped, the Devil Snare Keys numbers start at
1000 and Protego Keys numbers start at 2000
Keys are generated by the KeyGen application. If there is not a shortcut, open the
keyGen application in the folder "C:\RMS_Programs\keygen\keygen\bin\Release".
Create a folder where you want the key files to be placed. Enter the starting key
number and the number of keys. Click "Generate". The Keys will be placed in the
folder defined.
SECRET//NOFORN
SECRET//NOFORN
Step 3: Setting the Keys into the image:
Note: To run the required MPLAB applications you may have to create a user ID path to "C:\Program Files
(x86)\Microchip\MPLABX\mplab_ide\bin". See "Creating user ID path:" at the end of the document for an example.
P1, P2, and P3 are the only images that will contain unique keys. Use the setd.exe
app to set the keys into the images.
Copy the new key xxxx.dat files created in Step 2 into the _build directory created in
Step 1.
To build the image with a specific key:
1) Open a DOS command line prompt
2) In the command prompt window change directories into the new _build directory
Example:
> cd C:\RMS_Programs\20140925115118_build
3) Move the setd.exe into the new _build directory
located at: C:\RMS_Programs\setd\Release
4) To build an image with a specific key, execute the setd.exe application with the
proper arguments.
Example: > setd -k 3002.dat -i P1.X.production.hex -e P1.X.production.elf
5) The example in step 4, will only create the hex file for P1. An image for P2, and
P3 must also be created for a complete system.
Example for P1: > setd -k 3002.dat -i P1.X.production.hex -e P1.X.production.elf
SECRET//NOFORN
SECRET//NOFORN
Example for P2: > setd -k 3002.dat -i P2.X.production.hex -e P2.X.production.elf
Example for P3: > setd -k 3002.dat -i P3.X.production.hex -e P3.X.production.elf
Repeat building the P1, P2, and P3 key files as needed.
6) After all builds are completed and tested, capture the date stamp _build directory
with files into the software repository tag "file:///P:/18_0_Software"
Example:
20150109115839_build
Repository
/SVN/Task_1_Protego/tags/PROTEGO_RELEASE_BUILDS/20150109115839_build.
Creating user ID path:
1) Click Start , type Accounts in the Start search box, and then click User
Accounts under Programs.
2) In the User Accounts dialog box, click Change my environmental variables.
3) Add a new variable, PATH with the address C:\Program Files
(x86)\Microchip\MPLABX\mplab_ide\bin.
